PORTADRILLMINI MODELS > PORTADRILLMINI COMMERCIAL DIESEL DRILL UNIT BASIC ASSEMBLY
PORTADRILLMINI COMMERCIAL DIESEL DRILL UNIT BASIC ASSEMBLY

The product you selected is currently unavailable.

Price: $15,000.00
Availability: SOLD OUT - Place a reserved shipping work order
Prod. Code: PP20024N

                              CALL OR CONTACT  FOR CURRENT  AVAILABILITY  - CUSTOM BUILD ONLY .

         COMMERCIAL DIESEL  PORTADRILLMINI DRILL UNIT Specifications.
·          Height 9' 6"
·          Dry Weight - 710 lbs. (transportable) 990lbs. (Set up to drill)
·          Base width of machine 3’Ft.-Max width - 4' Ft.
·          Adjustable Mechanical cable pull down pressure system (Capable of lifting the machine off the ground)
·  ·          Drill diameters Tested from 1.5” up to 6” diameters
·           Drill Capacity mechanical rating   200 FT. (maximum drill depth UNKNOWN) MAXIMUM DEPTH REPORTED BY A GEOTHERMAL COMPANY IN  ROMANIA  IS 270  FEET.
·          THREE WAY INJECTION (Air/water/ mud injection and foam injection capabilities)
·          Minimum required air injection: 225 CFM @ 100 P.S.I.  to 120 P.S.I.
·          Drills 6" concrete (approx 5min)
·          One man portable operation
·          Confined location accessibility
·          Easier shipping than conventional rigs
·            Drills 30' coral rock solid formation –(1hr 15min)
·

PORTADRILLMINI DRILL COMMERCIAL DIESEL SUPER HEAVY DUTY MODEL.
 FOR MEDIUM TO HARD ROCK FORMATIONS, EXTENDED DURATION REPETITIVE USE DRILLING.
                *DRILL FEATURES  INCLUDED *
·          7 H.P. HATZ DIESEL    ENGINE
·          MAIN BASE STABILIZER RAILS
·          WEIGHT BAR PULL -DOWN ASSIST
·          MOBILE UNIT WHEEL DOLLY SYSTEM
·          AIR / WATER/ MUD INJECTION FLOW CONTROL VALVE SYSTEM
·          MAIN BASE WATER DEFLECTOR SHIELD
·          DRILL STEEL TABLE WATER DEFLECTOR SHIELD
·          MECHANICAL ADJUSTABLE PULL -DOWN PRESSURE SYSTEM
·          STEEL SWIVEL
·          STEEL MAST STRUCTURE CONSTRUCTION
·          DOUBLE SPOOL WINCH
·         25 -1 HEAVY USE DUTY GEAR BOX

.


PORTADRILLMINI ® DIESEL COMMERCIAL DRILL UNIT
 NEW 2021 MODEL Design
• Air-cooled single-cylinder 4-stroke Diesel engine. 7 H.P.
• Horizontal cylinder.
• Light alloy diecast cylinder crankcase.
• Light alloy cylinder head .
• Forged crankshaft.
• Light alloy piston for low free forces of gravity.
• Lubrication by pressurized circulation of oil, fine screen filtering in main flow.
• Valve control by rocker, push-rods and tappets.
Characteristics
• Direct injection.
• Compression 1:22. EXCELLENT  cold start performance.
• Fuel orientated mixture preparation. Result: excellent exhaust quality.
• Speed regulation by spring-loaded governor.
Proportionality < 5% at 3000 / 3600 r.p.m.
• The control cover houses the governor, the entire valve drive, the injector pump drive
and the automatic decompression system and oil pump.
• Dry air filter with paper cartridge and integrated pre-cleaner.
• Cooling fan and AC generator incorporated in the flywheel (not sensitive to dust).
• Exhaust outlet flexible as regards both position and direction of exit.


 PORTADRILLMINI ®   PATENT #   6,315,059
